Product Name：Side hydraulic circuit breaker
Product Details：
Versatile applications including rock crushing, paving, building demolition and more.
1.Reducing total-length2.More easier to handle the breaking objects3.Low maintenance
Specifications：
Item | Unit | LD100 | LD200 | LD300 | LD400 | LD600 | LD800 | LD900 | LD1600 |
Top Type Weight | kg | 85 | 140 | 160 | 355 | 440 | 640 | 900 | 1800 |
Box Type Weight | kg | 100 | 167 | 194 | 363 | 450 | 730 | 970 | 1950 |
Side Tyoe Weight | kg | 105 | 135 | 150 | 300 | 410 | 450 | 800 | 1600 |
Length | mm | 1000 | 1300 | 1400 | 1700 | 1750 | 2100 | 2400 | 2700 |
Pressure | bar | 90-120 | 90-120 | 90-120 | 110-140 | 110-160 | 120-170 | 150-170 | 160-180 |
Flow | lpm | 12-25 | 20-40 | 25-50 | 40-70 | 50-90 | 60-100 | 80-120 | 120-160 |
Rate | bmp | 900-1400 | 700-1200 | 600-1100 | 500-900 | 500-800 | 400-700 | 400-700 | 400-700 |
Hose | inch | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 |
chisel | mm | 40 | 45 | 53 | 68/70 | 75 | 85 | 100 | 135 |
Suit | ton | 0.8-2.0 | 1.2-3.0 | 2.5-4.5 | 4-7 | 6-9 | 7-14 | 11-16 | 19-26 |
